Product Name: | Hot Sale Bridge Type CMM Coordinate Measuring Machine | Model: | Helium |
---|---|---|---|
MPEe: | ≤ 1.8+L/350 (μm) | MPEp: | ≤ 1.8μm |
Linear Scale: | Renishaw 0.1μm | Waranty: | 12 Months |
Advantage: | Universal, Cheap, High Accuracy | ||
High Light: | CMM Coordinate Measuring Machine,Coordinate Measuring Machine Bridge Type,Helium Coordinate Measuring Machine |
Hot Sale Bridge type CMM Coordinate Measuring Machine
---------------------------------Product overview
“Helium” is characterized by the highest precision machine. Each part is selected strictly in the period of manufacturing and make sure that all parts are connected perfectly and opportunely in the period of assembly. The acceptance of measuring machines takes place according to ISO 10360-2. In doing so, two standardized acceptance procedures are used. All measuring machines are measured with an ultra precision laser. Afterward, a test conforming to standards with DKD-certified solid measures such as gauge blocks, ball plates, etc. is conducted. Therefore, the machine customers use at last is real high quality,high precision and German Technology.
Parameters
Product name |
Factory Direct Sale Bridge type Coordinate Measuring Machine CMM High Precision |
||||
Travel range (mm) |
Accuracy (um) |
||||
Helium |
X Axis |
Y Axis |
Z Axis |
MPEe |
MPEp |
500 |
500-1000 |
400,500 |
1.3+L/350 |
1.3 |
|
600,700 |
600-1000 |
600 |
1.3+L/350 |
1.3 |
|
800 |
800-1500 |
600,700 |
1.5+L/350 |
1.5 |
|
1000 |
1000-3000 |
800 |
1.5+L/350 |
1.5 |
|
Software system |
Measuring SW |
Rational-DMIS Advanced version (CAD) |
|||
Control system & probe system |
Include the joystick |
RENISHAW control system, include MCU joystick |
|||
Probe set |
RENISHAW MH20i/MCP/PH10T+TP20/PH10M+TP200/PH10M+SP25M/PH10MQ+SP25M... |
||||
Probe stylus |
RENISHAW M2 M3 stylus |
Features
CMM is mostly used in the company and near by the other machines and transport truck. The vibration influences the precision of CMM. Make a special foundation is one solution but this will cost and trouble. Our CMM has the patent support with double passive vibration damping Integrated directly in the machine frame. Thus the machine may be suitably positioned close to production. No need a special foundation for this CMM in most cases.
Worktable is the support of all the CMM, its quality is important for the performance! Our CMM is made with high precision, heavy and stable natural granite worktable from “Mount TAI”; this can support vibration damping and improve the performance of CMM.
The environment of the CMM has strict requirement, but some different such as the temperature and dust are possible in the measurement room. As a standard, all our CNC machines are fitted with enclosed guides. This protects the guideways from damage, dirt, and direct thermal influences. This can prevent external dust and temperature changes. It’s important for usage in dusty environment.
Key parts are most important for the stable of machine. Only with the best design and best quality of key parts can make the long time stable of CMM. All the key parts are famous brands(servo motor, transmission system, pneumatic system etc.). This can make best precision and service life of the CMM.
Optical scale is one of most important part for CMM; RENISHAW is the best flag in the domain of CMM parts. It has the best products and best service reputation! Our CMM use always RENISHAW high accuracy optical scale. Resolution is 0.5um.
Air bearing guide way using 4 sides surrounded structure! This is the symbol of stable and quality! In our CMM, each axis has many air pressure regulators in different directions and pneumatic bearings, annular pneumatic bearing design guaranties instruments steady during moving.
Air consumption: 150NL/Min. Small holes technology, this makes condensate zone between air bearing and guide way. It can offset the little heat comes from the motion friction! This technology improves the thermal stability of the CMM and keeps the long term precision stability.
Software
Rational-DMIS Software package
Rational - DMIS is a newly developed large-scale integrated 3D measurement software package. In addition to the development and design of the software, which takes into account the requirements of beginners for easy learning and use of the software and high-level users for the function of the software, more importantly, it becomes a model of CMM measurement software standardization.
Rational DMIS programs are designed with the full and native DMIS kernel until version 5.0 of DMIS, which is totally different from the so-called "support DMIS" (the kernel is not DMIS). As we all know, DMIS has become an ISO standard (ISO 22093:2003)
