Name: BASIC 200 Manual Vision Measuring System for 3C Components / Series of Vision Measurement Machines
Brand: Unimetro Precision Machinery Co., Ltd
SKU: BASIC
Price: 20,500.00 USD
Availability: InStock

Detail Information

Highlight:

vision measuring machine

vision measurement system

3C Vision Measurement Machine

Product Description

Manual Optical Instrument Video Measuring Machine for 2d Measurement

Vision measurement machine is an instrument used for accurate physical dimension measuring, accuracy up to micron level,Which is an optical measuring instrument using the camera to capture the image of the work piece, analyse the image pixel and calculate the 2D dimension with the measuring software.
BASIC Series vision measurement machine is designed and developed by UNIMETRO, which is a popular model fit for most of the accurate 2D dimension measuring application and end users from different industries, as Mold, Electronics, Semi conductor, Plastic Injection, 3C products, Medical care, Aviation...etc.It is an important instrument used in your products quality control process,ensuring your products dimension accuracy, makes your products more competitive.
BASIC series VMM is the most common model for most of the factories manufacturing accurate parts. It is fit for small quantity samples measuring application. 3 axis manual control, with user friendly software, allows the operator to manage using the machine in very short time.

Items		BASIC 200
Dimension(mm) (LWH)		550 X 540 X 830
Measuring range(mm)(XYZ)		200100150
Accuracy(μm)		2.5+L/200
Repeatability(μm)		2.5
Weight(kg)		140
Image and measurement	CCD	1.2M HD digital camera
	Zoom lens	Manual zoom lens 0.7-4.5X(Optional: electronic magnification signal feedback lens)
	Magnification	18-195X(According to different models of optional cameras, the magnification will change accordingly; the actual magnification is subject to the measured data)
	FOV	8.1~1.3mm(FOV will change according to the different matching schemes of the camera and the lens. Actual FOV field of view is subject to the measured data)
	Work distance	90mm
Linear scale resolution		0.5μm
Drive system		X/Y/Z axis manual control
illumination system		Programmable LED 8 section ring surface light, parallel light at the bottom of the LED (optional: coaxial light)

Software Functions
The UNIMETRO INSPECT3D software is with user friendly UI, easy to learn, powerful function, allows the users to achieve fast and precise measuring. The software is offering full English language UI, also allows new language development.

Application


AUTO PARTS	MOULD	HARDWARE	ELECTRONIC COMPONENT

Company Information

Our Client&Agent

FAQ
Q1: Are you a factory or trading company ?
A1: We are a factory and giving you the quickest reply in 24 hours.
Q2: What's your company mainly in?
A2: We are mainly produce Vision measuring machine,Coordinate measuring machine ,CMM&VMM fixturesetc.
Q3: How to Choose the Appropriate Specification?
A3: As long as you tell us variety and size of product to be measured, our professional team would advise you of measuring instrument of suitable specifications.
Q4: Do you accept customized service?
A4: Be sure! We can provide not only typical machines, but also the machines customized to customer's needs.
Q5: What is your warranty period?
A5: Our product warranty period is 1 year. Our product quality is very stable, and we have improved a lot on some breakable parts. You can rest assured of our product quality.

Tag:

Place of Origin:	China
Brand Name:	UNIMETRO
Certification:	CE,ISO
Model Number:	BASIC

Minimum Order Quantity:	1
Price:	Discussible
Packaging Details:	Case box
Delivery Time:	7 work days
Payment Terms:	T/T
Supply Ability:	10 per month
