Name: Fully Automatic VMA3020 Vision Measuring System with Automatic Edge Detection
Brand: Unimetro Precision Machinery Co., Ltd
SKU: ULTRA
Price: 20,500.00 USD
Availability: InStock

Detail Information

Product Name:	Vision Measurement Machine	Dimension(mm):	17509201700
Measuring Range(mm):	400300200mm	Measuring Accuracy:	2.5+L/200um
Repeatability:	2.5	Linear Scale Resolution:	0.1um
Driving System:	CNC Control,close-loop AC Servo Driving System,joystick,mouse Or Keyboard Control	Illumination:	Programmable 8 Sections LED Ring Light Parallel LED Contour Light
Highlight:	industrial ccd camera , industrial digital camera , VMA3020 Vision Measurement Machine

Product Description

Fully Automatic VMA3020 Vision Measuring System with Automatic Edge Detection

Full Automatic Control VMA3020 Vision Measurement Machine

ULTRA series Vision Measurement Machine is a cantilever high accuracy fully automatic vision measuring machine developed for GD&T measurement with 3 axis automatic motorized control. It is equipped with automatic focusing, automatic lighting control, and automatic movement of hardware and software configuration to make the measurement of linear and geometrical dimensions quickly and accurately.

Machine Characteristics

Quality Details Control

Granite base and column for excellent stability
Aluminum work stage for fast reacting and flexible motion control
Work stage with hard oxidation surface processing for anti-scratch protection
Standard precision linear guide, grinding ball screw and AC servo motor for precision and stability
Integrated control system with embedded motion control and signal control for extremely stable performance

High Performance Configuration

XYZ three axis CNC automatic control and accurate positioning
0.1 um high precision glass linear scale for positioning and measurement accuracy
GIGA high resolution color camera for clear observation and accurate measurement
6.5x high-resolution click zoom lens with accurate doubling and one-time pixel correction
Programmable surface 5-ring 8-division LED Cold Illumination and contour LED parallel illumination with intelligent light adjustment

Flexible Expansibility

Multiple types of non-contact sensors and fast fixturing systems available for different measuring requirements
Movable color LED ring light available for enhanced flexibility with different materials and shapes
Compatible with touch probe, non-contact measuring sensors and robot arm for increased measuring efficiency

Functions Introduction

Excellent object-oriented software architecture design ensures stable and reliable software
Professional SPC statistical analysis software seamlessly connected with test software
Super edge searching algorithm for accurate edge detection with shadow and imaging period
Various element construction functions including translation, rotation, extraction, combination, parallel, vertical, mirror image, symmetry, intersection, and tangent
Measurement data automatically exported to TXT, WORD, EXCEL and SPC Software Database
"Distribution" and "recovery" measurement modes for easier and faster operation
Software supports multiple national languages without requiring language packs
Free software upgrades for same type products

Technical Parameters

Model	ULTRA 300	ULTRA 400	ULTRA 500	ULTRA 600
X/Y-axis Travel(mm)	300x200	400x300	500x400	600x500
Z-axis Travel	200mm (can be raised according to customer requirements)
X/Y/Z-3 axis Linear Scale	Glass Linear Scale Resolution: 0.1um
Guidance Mode	Precision linear guide, double-track double slider guide
Operation Mode	Joystick controller, Mouse operation, automatic detection program
Accuracy	XYZ-axis: ≤2.5+L/200um
Repeatability	±2.5um
Video System - CCD	High definition 1/3" Color CCD Camera
Lens	6.5X continue click zoom lens; Optical Magnification: 0.7X-4.5X; Video Magnification: 26X~172X(21.5"monitor)
Illumination System - Contour	LED parallel contour illumination
Illumination System - Surface	0~255 Stepless adjustable 5-ring 8-division LED surface illumination
Magnification	0.7X~4.5X
Measuring Software	UNIMETRO 2D Fully Auto Measuring Software
Load Capacity	25Kg
Working Environment	Temperature 20℃±2℃, Humidity Range<2℃/hr, Humidity 30~80%, Vibration<0.002g, <15Hz
Power Supply	220V/50Hz/10A
Dimension(WDH)(mm)	16007801700	17509201700	1900x1080x1700	105012801700
Net Weight(kg)	380	450	600	800

* L is measuring length(mm), the mechanical accuracy of Z-axis and focus accuracy is related to the surface of the workpiece.

* Magnification is approximate value, it is related to the dimension of monitor and resolution.

* Field of view(mm) = (diagonal*Horizontal*Vertical)

* 0.5X or 2X objective is optional available, and realize image magnification: 13X~86X or 52X~344X.

Product Images

Our Clients & Agents

Frequently Asked Questions

Q1: Are you a factory or trading company?

A1: We are a factory and give you the quickest reply within 24 hours.

Q2: What's your company mainly involved in?

A2: We mainly produce Vision Measuring Machines, Coordinate Measuring Machines, CMM & VMM fixtures, etc.

Q3: How to Choose the Appropriate Specification?

A3: As long as you tell us the variety and size of product to be measured, our professional team would advise you of measuring instrument with suitable specifications.

Q4: Do you accept customized service?

A4: Absolutely! We can provide not only typical machines, but also machines customized to customer's specific needs.

Q5: What is your warranty period?

A5: Our product warranty period is 1 year. Our product quality is very stable, and we have improved significantly on breakable parts. You can rest assured of our product quality.

Tag:

Place of Origin:	China
Brand Name:	UNIMETRO
Certification:	CE,ISO
Model Number:	ULTRA

Minimum Order Quantity:	1
Price:	Discussible
Packaging Details:	Wooden Case
Delivery Time:	15~20 work days
Payment Terms:	T/T
Supply Ability:	20 per month
