Name: Bridge CMM Compatible Holding Fixture – Surface Plate Fixture for Inspection Gauges
Brand: Unimetro Precision Machinery Co., Ltd
SKU: UTE-1
Price: 20,500.00 USD
Availability: InStock

Detail Information

Supporting Tools:	Milling Tools, Drilling Head	Measuring Device:	Dial Gauge
End Clamp:	Included	Tool Length:	Up To 150mm
Tool Diameter:	Up To 25mm	Rotating Control:	Automatic
Highlight:	Diameter Error CMM Fixture Kits , Tool Measuring CMM Fixture Kits , Roundness Tester CMM Fixturing Kit

Product Description

Bridge CMM Compatible Holding Fixture – Surface Plate Fixture for Inspection Gauges

Tool Measuring CMM Fixture Kits for Roundness Testing

The UTE-1 series tool testing fixture is specifically designed for roundness measuring of milling tools, drills, and long rod materials. With its rational design and stable base, this fixture enables high-accuracy tool measuring at an extremely low cost.

Product Overview

The UTE-1 series utilizes a DC motor for rotating movement control with adjustable RPM, ensuring stable motion during roundness measurement operations.

High Performance Linear Guide Way

The UTE-1 series tool fixture incorporates high-performance HIWIN linear guide ways, ensuring exceptional stability for dial gauge movement and maintaining superior measuring accuracy.

High Accuracy Ceramic Supporter

Featuring a V-type supporter made from high-accuracy ceramic material, this fixture achieves tool locating repeatability of less than 0.001mm. The ceramic construction ensures extended product lifecycle and facilitates easy replacement when needed.

Optional Dial Gauge and Gauge Fixture

Standard with M8 screw holes for gauge installation, the UTE-1 series accommodates various brands and types of gauges or gauge fixtures, providing flexibility to meet diverse measuring requirements.

Stable End Clamp Fixing

Equipped with end clamp fixing screws, the UTE-1 series enables convenient adjustment of measuring length to accommodate different tool types, ensuring optimal positioning for accurate measurements.

High Accuracy Tools End Supporter

To ensure stable tool location throughout the measuring process, the UTE-1 series includes an adjustable supporter on the tool end side, enhancing measurement reliability and consistency.
