Compact Vision Dimension Measurement System For Rapid, In-Line Batch Testing

Compact Vision Dimension Measurement System For Rapid, In-Line Batch Testing
Compact Vision Dimension Measurement System For Rapid, In-Line Batch Testing
Compact Vision Dimension Measurement System For Rapid, In-Line Batch Testing
Basic Information
Place of Origin: China
Brand Name: UNIMETRO
Certification: CE,ISO
Model Number: AVANT100
Minimum Order Quantity: 1
Price: Discussible
Packaging Details: Wooden case
Delivery Time: 15 work days
Payment Terms: T/T
Supply Ability: 100 per month
Get Best Price Contact Now
Detail Information
Product Name: Compact Design Image Dimension Measurement Machine With Large FOV Image Sensor: 2000W HD Color Digital Camera
Light Receiving Lens: Single/double Telecentric Lens Broad Vision: 130*100mm
Repeatability: +-2(coordinate Table Not Moving) Display Resolution: 0.1um
Warrenty: 12 Months Dimension: 415*240*768mm
Highlight:

High Resolution Industrial Camera

,

Large FOV Image Dimension Measurement System

,

High Resolution Image Dimension Measurement System

Product Description

Compact Vision Dimension Measurement System
Rapid, in-line batch testing solution for precision dimensional measurement
Advanced Image Dimension Measurement Technology
The A100 image size measurement system represents UNIMETRO's innovative approach to dimensional measurement. Unlike traditional two-dimensional image measuring instruments, this system eliminates the need for grating scale displacement sensors and large focal length lenses while maintaining exceptional accuracy.
Key System Components
Streamlined body structure featuring telecentric zoom lens with large viewing angle and depth of field, high-pixel CCD camera, and powerful background software for comprehensive measurement capabilities.
Measurement Technology
Utilizing bi-telecentric optical lens technology with large viewing angle and depth of field, combined with high-speed digital processing and precision image analysis algorithms. Complete dimensional tolerance evaluation with single-key operation.
Industry Applications
Widely used across multiple industries including machinery, electronics, molds, injection molding, hardware, rubber, low-voltage electrical appliances, magnetic materials, precision stamping, connectors, terminals, mobile phones, household appliances, printed circuit boards, medical equipment, clocks, and cutting tools.
System Characteristics
Fast and Efficient Operation
  • Products can be placed freely on workbench without additional fixtures
  • Rapid measurement capability - up to 512 parts measured simultaneously
  • Enhanced batch measurement efficiency with quick, accurate CNC mode operation
Accurate and Consistent Results
  • One-click operation delivers precise, consistent measurement results
  • Software autofocus eliminates deviation from manual focus adjustment
  • Automatic measurement position identification ensures stable, unified results
Easy and Simple Operation
  • Quick user onboarding reduces manual training time
  • Simple operation interface with easy function access
  • Virtual lines and points creation for expanded measurement requirements
Technical Parameters
Model Number A100
Image Sensor 2000W HD Color Digital Camera
External Display 24-inch
Light Receiving Lens Single/Double Telecentric Lens
Illumination - Drop Shot System Single Zone Ring Directional Lighting (White Light)
Illumination - Transmission Telecentric Transmission Illumination (White Light)
Broad Vision (mm) 83×63mm
Repeatability - Broad Vision ±3 (Coordinate Table Not Moving)
Measurement Software INS/F
Display Resolution 0.1μm
Z-Direction Electric Coordinate Table - Moving Range 100mm
Dimension 240×415×770
Weight 50KG
Power Supply 110-240VAC, 50/60HZ
