CNC Optical Vision Measuring System, Compact Design with CE Certification

Optical Measurement Equipment is an instrument used for accurate physical dimension measuring with precision up to micron level. This vision measuring machine utilizes camera technology to capture workpiece images, analyze image pixels, and calculate 2D dimensions using advanced measuring software.

The CNC Optical Measurement Equipment is a powerful dimension measuring device designed for mass production quality control processes. Configured with powerful software that makes the measuring process programmable, users can achieve high-volume product measurement through fully automatic processes. The PEAK series Optical Measurement Equipment is an economical model of full automatic CNC vision systems developed by UNIMETRO.

The simple and integrated design enables cost-effective manufacturing while maintaining high measuring accuracy and optimal performance. Users benefit from high efficiency and labor cost savings with a fully CNC vision measuring machine at a competitive price.

• Compatible with full line of Omron fiber measuring sensors for enhanced precision measurement capabilities
• Stable measurements of inclined or curved surfaces
• Stable measurements of different material types
• Stable measurements of smooth or coarse surfaces
• Compatible with Renishaw touch probe for optional 2D and 3D measuring functionality in one machine
• Software calculates offset between optical lens and touch probe, ensuring all measurements are within one coordinate system
• Measuring results can be output as 3D drawings for reverse engineering applications

The UNIMETRO INSPECT3D software features a user-friendly interface that is easy to learn while offering powerful functionality for fast and precise measuring. The software provides full English language UI and supports additional language development.
