Large Range Visual Measuring Machine Gantry Type High Accuracy

Basic Information
Place of Origin: Guangdong, China
Brand Name: UNIMETRO
Certification: ISO, CE
Model Number: ULTRA400
Minimum Order Quantity: 1 set
Price: Negociatable
Packaging Details: Wooden case+ Vacuum packing
Delivery Time: 8-15days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50-60sets per month
Detail Information
Features: High Accuracy, Fast Speed Product Name: 400x300mm Travel Auto Non-Contact Coordinate Measuring Systems
Model: ULTRA400 Measuring Mode: Full-auto
Accuracy: 2.5+L/200 Repeatability: 2.5um
Support: OEM, ODM
High Light:

Large Range Visual Measuring Machine

,

Visual Measuring Machine Gantry Type

,

Visual Measuring Machine High Accuracy


Product Description

400x300mm Travel Auto Non-Contact Coordinate Measuring Systems



MODEL: ULTRA400


SPECIFICATIONS:



Product Name 400X300mm Travel Auto Non-contact Coordinate Measuring System
Model ULTRA400
X/Y-axis Travel 400*300mm
Z-axis Travel 200mm (can be raised according to the requirements of the customer)
Linear Scale Resolution 0.1um
Guidance Mode Precision linear guide, double-track double slider guide
Operation Mode Joystick controller, Mouse operation, automatic detection program
Accuracy ≤2.5+L/200um
Repeatability ±2.5um
Video System CCD High definition 1/3" Color CCD Camera
Zoom Lens 6.5X continue click zoom lens; Optical Magnification: 0.7X-4.5X;
Video Magnification: 26X~172X(21.5”monitor)
Illumination System Contour LED parallel contour illumination
Surface 0~255 Stepless adjustable 5-ring 8-division LED surface illumination
Load Capacity UNIMETRO 2D Fully Auto Measuring Software
Working Environment 25kg
Power Supply Temperature 20℃±2℃, Humidity Range<2℃/hr,
Humidity 30~80%, Vibration<0.002g, <15Hz
Dimension(W*D*H) 1750*920*170mm
Net Weight 450kg





CHARACTERISTIC:



Flexible configuration combination:

There is a standard configuration that would meet most of needs of end-users, but it is not fixed always. We will change the hardware assembly according to the actual requirement. For example, when you are going to test the simple height of the workpiece, you can just choose to add optional accessories like OMRON laser or Renishaw probe, etc.



Higher accuracy control:

In the dimension metrology field, accuracy is the key point of machine quality. To achieve higher accuracy, UNIMETRO team have totally 6 inspection link, from sampling inspection for all raw materials to 48-hours accuracy testing before shipment.




Efficient measurement software:
1. With the External-Array RationalVue composite measuring software, the ULTRA series is capable to offer powerful 2D/3d composite measuring function;
2. Simple and easy to understand operation interface makes measurement more simple and efficient;
3.Automatic measurement program can be set to complete batch measurement efficiently and quickly.





SOFTWARE:



INSPECT 3D VISION MEASURING SOFTWARE

Large Range Visual Measuring Machine Gantry Type High Accuracy 0

◉ Flexible user program



◉ Creating reference elements



◉ Powerful edge detecting function



◉ Supporting multiple external accessories



◉ Auto calculation of the elements geometrical tolerance



◉ Measuring complicated production fast and conveniently





COMPANY PROFILE:



Large Range Visual Measuring Machine Gantry Type High Accuracy 1

UNIMETRO is a global contender and one of the top-ranking suppliers of testing technologies worldwide. With our extensive portfolio of state-of-the-art and competitively priced testing machines, systems and software, we supply standard or customized solutions for many tests, measurement and quality control tasks required in the world of modern materials testing.
The key products from UNIMETRO range include video measurement systems, coordinate measuring machine, roughness measuring equipment microscopy, portable testers, and instruments for testing metals, rubber, cement, concrete, as well as technologies for automotive, aerospace, mining, oil/gas/pipe industries, gold & Jewellery applications and much more.
We are at the beginning of an economically sensitive era and UNIMETRO has never been better positioned to meet the needs of the thousands of customers who will join us and benefit from our vast array of testing, measurement and quality control technologies in the coming years. By offering the best value for the investment our customers make, Qualitest will deliver state-of-the-art quality products and technologies that meet and exceed our customers requirements in testing world.
