Modularization Industrial Microscopes Metallographic Polarizing / Dark Field

Basic Information
Place of Origin: China
Brand Name: UNIMETRO
Model Number: U3203/3220/3230/3230BD
Minimum Order Quantity: 1
Price: Discussible
Packaging Details: Paper box
Delivery Time: 10 work days
Payment Terms: T/T
Supply Ability: 10 per month
Detail Information
UIS Optical System: Available Polarizing Observation: Available
Dark Field Observation: Available Transmitted Illumination System: Abbe Condenser NA.1.25 Rack & Pinion Adjustable
Nosepiece: Quintuple (Backward Ball Bearing Inner Locating) Eyepieces Tube: Trinocular Inclined 30˚, Can Be Shot In 100% Light Flux
High Light:

inverted metallurgical microscope

,

optical metallurgical microscope


Product Description



Upright Metallurgical Industrial Microscope Polarizing And Dark Field



Features



. Excellent UIS optical system

. Modularization function design

. Synchronous reflecting and transmitting or independent illumination

. Polarizing observation

. Dark field observation



Introduction



U3203/3220/3230/3230BD series upright metallurgical industrial microscopes is suitable for observing surfaces of opaque object or transparent object. It is equipped with excellent UIS optical system and modularization function design, provides excellent optical performance and continuous products upgrade, also to obtain synchronous reflecting and transmitting or independent illumination, or polarizing observation, or dark field observation.



U3203/3220/3230/3230BD series upright metallurgical industrial microscopes is with smart design, easy operation and clear image system, it is the ideal instruments for biology, metallography, mineralogy, precision engineering, electronics, etc usage.



Parameters

Specification

Eyepiece

Wide field WF10X(field number:Φ22mm)

Infinity plan achromatic objective

U3203/3220/3230 (Equipped with bright field objectives)

PL L5X/0.12 (Work distance):26.1 mm

PL L10X/0.25 (Work distance):20.2 mm

PL L40X/0.60 (Work distance):3.98 mm

PL L60X/0.70 (Work distance):3.18 mm

U3230BD (Equipped with bright & dark field objectives)

PL L5X/0.12 BD (Work distance):9.7 mm

PL L10X/0.25 BD (Work distance):9.3 mm

PL L20X/0.40 BD (Work distance):7.2 mm

PL L40X/0.60 BD (Work distance):3.0 mm

Eyepieces tube

Trinocular inclined 30˚, can be shot in 100% light flux.

Epi- illumination system

U3203/3220/3230

6V 30W, halogen lamp and adjustable brightness.

U3230BD

12V 50W, halogen lamp and adjustable brightness.

U3203/3230/3230BD

Equipped with Y, B, G filters and ground glass

U3220

Equipped with Y, B, G, R filters.

Integrated field diaphragm, aperture diaphragm and filter switching device. Push-pull type analyzer and polarizer

Focus system

Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm.

Nosepiece

Quintuple (Backward ball bearing inner locating)

Stage

Double layer mechanical stage, overall size:210mmX140mm,moving range:75mmX50mm.

Transmitted illumination system

Abbe condenser NA.1.25 Rack & pinion adjustable

Collector for halogen lamp illumination and integrated field diaphragm

U3230/3230BD

Equipped with B filter and ground glass

U3220

Equipped with B, G filters and ground glass.

U3220/3230

6V 30W, halogen lamp and adjustable brightness.

U3230BD

12V 30W, halogen lamp and adjustable brightness.

Optional Accessory

10X(Φ22mm)Dividing eyepiece(Φ22mm)

6V 30W, halogen lamp and adjustable brightness.

Objective

U3203/3220/3230

20X,50X,80X,100X(Dry) Bright field objective

CCD adapter

0.5X,1X,0.5X (With dividing)

Camera

50X,60X,80X,100X Bright & dark field objective

Digital camera adapter

50X,60X,80X,100X Bright & dark field objective





Company Information

Visual Measurement Machine
Visual Measurement Machine
Visual Measurement Machine
Visual Measurement Machine

Our Client&Agent

Visual Measurement Machine
Visual Measurement Machine
FAQ
Visual Measurement Machine  Q1: Are you a factory or trading company ?
Visual Measurement Machine  A1: We are a factory and giving you the quickest reply in 24 hours.
Visual Measurement Machine  Q2: What's your company mainly in?
Visual Measurement Machine  A2: We are mainly produce Vision measuring machine,Coordinate measuring machine ,CMM&VMM fixturesetc.
Visual Measurement Machine  Q3: How to Choose the Appropriate Specification?
Visual Measurement Machine  A3: As long as you tell us variety and size of product to be measured, our professional team would advise you of measuring instrument of suitable specifications.
Visual Measurement Machine  Q4: Do you accept customized service?
Visual Measurement Machine  A4: Be sure! We can provide not only typical machines, but also the machines customized to customer's needs.
Visual Measurement Machine  Q5: What is your warranty period?
Visual Measurement Machine  A5: Our product warranty period is 1 year. Our product quality is very stable, and we have
improved  a lot on some breakable parts. You can rest assured of our product quality.





Notice: The transmitted and reflected illumination system of the mode U3220 are controlled independently.
