Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC

Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC

  • Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC
  • Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC
Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC
Product Details:
Place of Origin: China
Brand Name: UNIMETRO
Model Number: UJL-20BDDIC
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Discussible
Packaging Details: Paper box
Delivery Time: 10 work days
Payment Terms: T/T
Supply Ability: 10 per month
Contact Now
Detailed Product Description
Eyepiece Tube: Inclination 45°and Interpupillary Distance:53~75mm DIC Switching Device: Suitable For LMPlan 5X、10X、20X BDDIC Objective
Eyepiece: Wide Field WF10X(Φ22mm) Illumination System: 12V50W Halogen Lamp,brightness Adjustable
Filters: Equipped With Frosted Glass And Yellow ,green And Blue Filters Product: Industrial Microscopy
High Light:

optical metallurgical microscope

,

metallurgical optical microscope



Inverted Metallurgical Industrial Microscopes Bright Field Dark Field DIC



Introduction



The UJL-20BDDIC DIC Inverted Metallurgical Industrial Microscopes are suitable for bright field and dark field differential interference contrast observation. it is equipped with excellent UIS optical system and modularization design, providing outstanding optical performance and capability of system upgrading. the UJL-20BDDIC DIC Inverted Metallurgical Industrial Microscopes series is a powerful observing tool for detecting and analysis in precise engineering area.



Illumination System



Using the Kohler illumination, the aperture stop and field stop are adjustable. Illumination coolant is considered, ensures the surface temperature is under controller, offers safer operation. Easy changing of the lamp, not requiring any tools.



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 0       Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 1



Observing system



The gemel mode trinocular is inclined 45 degrees, offers comfortable operation for the users.
The eyepiece field of view is Ф22mm.



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 2



Mechanical stage



The circular chromeplate rotating plate is located in the center of the mechanical stage to achieve rotation of the specimen during the polarization observation process.
The abnormity observation window is suitable for different size of specimen.



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 3



Photography unit



The photographic observation output adapter is located on the back of the frame, to avoid interference
to the eyepiece observation.The microphotography is in 100% light flux, which is suitable for low

brightness illumination status.



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 4



DIC observation



The dark field and bright field differential interference contrast DIC system are both available in the UJL-20BDDIC DIC Inverted Metallurgical Industrial Microscope.


The series is equipped with high quality DIC objectives and switching device, to show the users clear, sharp edge and 3D embossed images.



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 5  Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 6

Bright Field DIC observation         Dark Field DIC observation



Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 7  Industrial Inverted Metallurgical Microscope For Bright Field / Dark Field DIC 8



DIC observation accessories



Specification



Specification
Eyepiece Wide field WF10X(Φ22mm)

Objective

(Equipped with bright & dark field DIC objective)



Infinity plan achromatic objectives with long working distance(no cover glass)
LMPlan5X/0.12 BDDIC Work distance:7.9 mm
LMPlan10X/0.25 BDDIC Work distance:20.2 mm
LMPlan20X/0.35 BDDIC Work distance:3.04 mm
PL L40X/0.60 BD Work distance:3.00 mm
DIC switching device Suitable for LMPlan 5X,10X,20X BDDIC objective
Eyepiece tube Inclination 45°and interpupillary distance:53~75mm
Focus system Coaxial coarse/fine focus with tension adjustable and up stop,minimum division of fine focusing:2.0μm.
Nosepiece Quintuple(backward ball beaing inner locating)
Stage Mechanical stage,size:242mmX200mm,moving range: 30mmX30mm.
Rotundity and rotatable stage size:Ф130mm minimal clear aperture is less then Ф20mm
Illumination system 12V50W halogen lamp,brightness adjustable
Integrated field diaphragm ,aperture diaphragm and system polarizer
Equipped with frosted glass and yellow ,green and blue filters
