Optical Linear Scale Gauge for Height Measurement / 0.02mm Resolution with Imperial Units

Basic Information

Place of Origin:	China
Brand Name:	UNIMETRO
Model Number:	UGHT-S

Minimum Order Quantity:	1
Price:	Discussible
Packaging Details:	Paper box
Delivery Time:	7 work days
Payment Terms:	T/T
Supply Ability:	30 per month

Get Best Price Contact Now

Detail Information

Scale Material:	Stainless Steel	The Curve Lines On The Scale Body:	Brightless Chrome-plating, Clear And Stable
Fine Adjusting Device:	Included	Resolution:	0.02mm, 0.001”
Gauge Plate:	Adjustable	Packaging Wood Box:	Included
Highlight:	linear digital scale , optical linear encoder

Product Description

Optical Linear Scale Gauge for Height Measurement

Precision height measuring instrument with 0.02mm resolution and imperial unit capability

Product Features

Constructed from durable stainless steel material
Bright chrome-plated curved lines on scale body for clear, stable readings
Integrated fine adjusting device ensures high accuracy measurement requirements
Dual resolution: 0.02mm and 0.001"
Adjustable gauge plate for versatile applications
Includes protective wooden packing box
Rigid alloy measuring clamp with precision curved lines
Hardened integer base for enhanced durability

Metric Models

Model	Measuring Range	Resolution	Accuracy
3121-152	0-150mm	0.02mm	+0.02mm
3321-202	0-200mm	0.02mm	+0.03mm
3321-302	0-300mm	0.02mm	+0.04mm

Imperial Models

Model	Measuring Range	Resolution	Accuracy
3121-150	0-6"	0.001"	+0.001"
3321-200	0-8"	0.001"	+0.001"
3321-300	0-12"	0.001"	+0.0015"

Dual Unit Models (Metric & Imperial)

Model	Measuring Range	Resolution	Accuracy
3121-150	0-150mm/6"	0.02mm/0.001"	+0.001"
3321-200	0-200mm/8"	0.02mm/0.001"	+0.001"
3321-300	0-300mm/12"	0.02mm/0.001"	+0.0015"

Dual Unit Models (Imperial & Metric)

Model	Measuring Range	Resolution	Accuracy
3121-150	0-6"/150mm	0.001"/0.02mm	+0.001"/0.02mm
3321-200	0-8"/200mm	0.001"/0.02mm	+0.001"/0.03mm
3321-300	0-12"/300mm	0.001"/0.02mm	+0.001"/0.04mm

Company Information

Our Clients & Agents

Frequently Asked Questions

Q1: Are you a factory or trading company?

A1: We are a factory and provide responses within 24 hours.

Q2: What does your company primarily manufacture?

A2: We specialize in producing Vision Measuring Machines, Coordinate Measuring Machines, CMM & VMM fixtures, and related precision measurement equipment.

Q3: How to choose the appropriate specification?

A3: Our professional team will recommend suitable measuring instruments based on your product variety and measurement requirements.

Q4: Do you accept customized service?

A4: Yes, we provide both standard machines and custom solutions tailored to specific customer needs.

Q5: What is your warranty period?

A5: Our products come with a 1-year warranty. We maintain high product quality standards and have enhanced durability on critical components.
